Description
Low-Voltage Power Unit
Built with a lightweight, compact body, this 105VA electronic unit passes easily through standard downlight ceiling cut-outs for effortless void mounting in domestic and commercial premises.
Fully dimmable with trailing-edge phase dimmers, this transformer provides smooth light regulation across living rooms, retail displays, and office environments across the UK.
Key Features & Benefits
-
Wide Load Capacity: Supports 35W to 105VA loads for versatile low-voltage 12V lighting installations
- Fully Dimmable: Compatible with trailing-edge electronic dimmers for smooth, flicker-free light regulation.
Specifications
| Feature | Specification |
| Product Code / SKU | 213353 |
| Model / Series | 12 Volt 105 VA Transformer 213353 |
| Product Type | Electronic Low-Voltage Transformer |
| Primary Voltage (Input) | 220–240V AC 50/60Hz |
| Secondary Voltage (Output) | 12V AC |
| VA / Wattage Rating | 35VA – 105VA |
| Dimmable | Yes (Trailing-Edge Compatible) |
| IP Rating | IP20 (Indoor Use) |
| Protection Class | Class II (Double Insulated) |
| Safety Protection | Thermal Overload, Short-Circuit, Over-Power |
| Construction | Polycarbonate Enclosure |
| Finish | White |
| Warranty | 2 Years |
